AN Stainless Steel Double Banjo Bolts – Dual Line Connections for Brake & Clutch Systems

Our AN Stainless Steel Double Banjo Bolts are designed to connect two banjo fittings at a single threaded port. Ideal for brake, clutch and other hydraulic systems, each bolt is precision CNC machined in the UK from stainless steel for excellent strength, durability and corrosion resistance.

Key Features

Premium Stainless Steel Construction

Precision CNC machined from 303/304 stainless steel for excellent strength, durability and corrosion resistance in road, race and motorsport applications.
Designed for Two Banjo Fittings

The extended hollow bolt design accommodates two banjo fittings at a single threaded port, allowing two hydraulic lines to be connected at one mounting point.
AN3 Thread

Available with an AN3 (3/8"-24 UNF) thread for compatible brake, clutch and hydraulic components.
Crush Washer Sealing

Three crush washers are required for installation – one on each outer side of the two banjo fittings and one between them. Copper Crush Washers are available separately.

What is a Double Banjo Bolt?

A double banjo bolt is a hollow fastener designed to secure two banjo fittings to a single threaded hydraulic port. Internal passages allow fluid to flow through the bolt and into both banjo fittings while the assembly is sealed using crush washers.

Installation

Each double banjo bolt requires three copper crush washers (not included) – one between the component and first banjo fitting, one between the two banjo fittings, and one beneath the bolt head.

Bolt Type: Double Banjo Bolt Designed for use with two banjo fittings
Head Type: Hex Head Standard spanner installation
Material: 303/304 Stainless Steel Excellent strength and durability
Finish: Natural Stainless Steel Corrosion-resistant
Manufactured In: United Kingdom Precision CNC machined

Flow Design: Unrestricted No internal flow restriction
Seal Type: Crush Washers Three required for installation

Available AN stainless steel double banjo bolt sizes and dimensions
Product Code	Thread	Thread Length	Bolt Length Below Hex Head	Spanner Size
BLT-DBL-SS-AN3	3/8"-24 UNF AN3	11mm	29mm	14mm

Brake Systems
Clutch Systems
Hydraulic Systems
Dual Brake Line Installations
Brake Line Distribution

Brake Fluid
Clutch Fluid
Hydraulic Fluid

Copper Crush Washers

Three crush washers are required for installation, one either side of the banjo fittings and one between them.

Free repair or replacement for two years from the date of purchase. Learn more

Frequently Asked Questions

What is a double banjo bolt used for?
A double banjo bolt allows two banjo fittings to be connected to a single threaded hydraulic port. It is commonly used where two brake, clutch or other hydraulic lines need to share the same connection point.
What thread size is the AN Double Banjo Bolt?
The AN version uses an AN3 (3/8"-24 UNF) thread.
Can two banjo fittings be fitted to one bolt?
Yes. These bolts are specifically designed to accommodate two banjo fittings at a single threaded port.
What material is the AN Double Banjo Bolt made from?
It is precision CNC machined in the UK from 303/304 stainless steel for excellent strength, durability and corrosion resistance.
How many crush washers are required?
Three crush washers are required – one on each outer side of the two banjo fittings and one between them. Copper Crush Washers are available separately.
Does any 3/8"-24 UNF port accept this banjo bolt?
The threaded port must use the correct 3/8"-24 UNF thread and also be suitable for a banjo bolt connection. Always confirm the component specification and required bolt dimensions before installation.
