Hose Finisher Clamps

Maximum Hose Outside Diameter

Info

Measure the outside diameter of your hose and select the smallest size equal to or greater than your measurement.

For example:

13mm hose → 14mm
16mm hose → 17mm
18mm hose → 21mm

£4.40

In Stock

Free 100-day Returns

no questions asked

Free UK Delivery over £30

express options available

2-Year Warranty

free repair or replacement

Aluminium Hose Finisher Clamps for Clamp-Type Hose Connections

These aluminium hose finisher clamps combine a lightweight 6061-T6 aluminium outer body with an internal stainless steel worm-drive clamp. The clamp secures compatible hose onto a suitable hose tail or barb while the outer body conceals the clamp and cut hose end for a clean finished appearance.

6061-T6 Aluminium Construction

The outer finisher is manufactured from 6061-T6 aluminium with a black anodised finish, while the adjustable internal worm-drive clamp is manufactured from stainless steel.

Rubber & Silicone Hose Compatibility

Suitable for braided rubber hose, standard rubber hose and silicone hose where a clamp-type connection onto a compatible hose tail or barb is appropriate.

These hose finishers are not suitable for PTFE hose. PTFE hose requires compatible PTFE hose-end fittings rather than this clamp-type connection.

Choose by Actual Hose Outside Diameter

Measure the actual outside diameter (OD) of the hose and select the smallest finisher with a maximum hose outside diameter equal to or greater than that measurement. The available options are shown in the Specifications.

Push-On & Clamp Installation

Slide the finisher over the hose, fit the hose onto a compatible hose tail or barb, position the internal worm-drive clamp correctly over the connection and tighten the clamp to secure the hose.

Finisher Material: 6061-T6 Aluminium Lightweight, high-strength alloy
Finish: Black Anodised Protects against wear and corrosion
Clamp Material: Stainless Steel Durable and corrosion-resistant
Clamp Type: Worm Drive Adjustable internal clamp concealed within the aluminium finisher
Installation: Push-On & Clamp For compatible hose tail or barb connections

Braided Rubber Hose
Rubber Hose
Silicone Hose

These hose finishers are not suitable for braided PTFE hose. PTFE hose requires compatible braided PTFE hose fittings rather than this clamp-type connection.

Available maximum hose outside diameters for hose finisher clamps
Product Code	Maximum Hose Outside Diameter
FIN-AL-14	14mm 0.55"
FIN-AL-17	17mm 0.67"
FIN-AL-21	21mm 0.83"
FIN-AL-24	24mm 0.94"
FIN-AL-29	29mm 1.14"
FIN-AL-38	38mm 1.50"

Selecting a Size: Measure the outside diameter (OD) of the hose and select the smallest finisher with a maximum hose outside diameter equal to or greater than the measured hose OD.

Free repair or replacement for two years from the date of purchase. Learn more

Frequently Asked Questions

What is an aluminium hose end finisher?
An aluminium hose end finisher combines an aluminium outer body with an internal stainless steel worm-drive clamp. The clamp secures compatible hose onto a suitable hose tail or barb, while the aluminium body conceals the clamp and cut hose end.
Which types of hose are compatible?
These hose finishers are suitable for braided rubber hose, standard rubber hose and silicone hose where a clamp-type connection onto a compatible hose tail or barb is appropriate.
Can I use these hose finishers with PTFE hose?
No. PTFE hose requires compatible PTFE hose-end fittings and should not be secured using this clamp-type hose finisher.
How do I choose the correct hose finisher size?
Measure the outside diameter (OD) of the hose and select the smallest finisher with a maximum hose outside diameter equal to or greater than the measurement. The available options are shown in the Specifications.
What materials are the hose finishers made from?
The outer finisher is manufactured from 6061-T6 aluminium with a black anodised finish. The internal worm-drive clamp is manufactured from stainless steel.
How do I install a hose end finisher?
Slide the finisher over the hose, fit the hose onto a compatible hose tail or barb, position the internal worm-drive clamp correctly over the connection and tighten it to secure the hose.
Does the hose finisher include the clamp?
Yes. The stainless steel worm-drive clamp is incorporated inside the aluminium hose finisher.
Can a hose finisher cover the cut braid on stainless steel braided rubber hose?
Yes. When used with compatible stainless steel braided rubber hose, the aluminium body encloses the cut end of the outer braid and conceals the internal clamp.
