AN Female to AN Female Adapters

Size

£7.71

In Stock

Free 100-day Returns

no questions asked

Free UK Delivery over £30

express options available

2-Year Warranty

free repair or replacement

AN Female to AN Female Swivel Adapters

These AN female to AN female adapters provide a compact way to join two compatible male AN connections, including fittings, adapters and hose assemblies.

Dual Swivel Female Connections

Both female AN connections swivel independently, making it easier to align and tighten the adjoining fittings during installation without rotating the connected components.

JIC 37° Flare Sealing

Each female AN connection uses a JIC 37° flare seat. The connection seals between the mating flare surfaces rather than on the threads, so PTFE tape or thread sealant is not required on the AN connections.

6061-T6 Aluminium Construction

The adapters are manufactured from 6061-T6 aluminium with a black anodised finish.

Type: AN Female to AN Female Adapter For joining two compatible male AN connections
Material: 6061-T6 Aluminium Lightweight, high-strength alloy
Finish: Black Anodised Protects against wear and corrosion

Connection 1: AN Swivel Female JIC 37° · Female cone flare
Connection 2: AN Swivel Female JIC 37° · Female cone flare

Available AN female to AN female adapter sizes
Product Code	Connection 1	Connection 2
ADP-FF-AN-AL-AN6	AN6 Swivel Female 9/16"-18 UNF	AN6 Swivel Female 9/16"-18 UNF
ADP-FF-AN-AL-AN8	AN8 Swivel Female 3/4"-16 UNF	AN8 Swivel Female 3/4"-16 UNF
ADP-FF-AN-AL-AN10	AN10 Swivel Female 7/8"-14 UNF	AN10 Swivel Female 7/8"-14 UNF

Fuel Systems
Oil Systems
Coolant Systems
Custom Fluid Systems

Free repair or replacement for two years from the date of purchase. Learn more

Frequently Asked Questions

What are AN female to AN female adapters used for?
They connect two compatible male AN connections directly together, including hose fittings, adapters and other AN components.
Do both female connections swivel?
Yes. Both female AN connections swivel independently, allowing the adjoining fittings to be aligned and tightened during installation.
How do the connections seal?
Both connections use JIC 37° flare sealing. The female flare seats seal against the corresponding male 37° cone flares.
Do I need PTFE tape or thread sealant?
No. The AN connections seal on the mating JIC 37° flare surfaces rather than on the threads, so PTFE tape or thread sealant is not required.
